Featured Case Studies - Wireless Applications

Please contact us for permission to re-publish these case-studies or to discuss your individual application. Also see link below for generic application notes & CAD drawings from past projects covering different wireless solutions. Rfwel is a licensed communication contractor AZ ROC #253407 and an experienced wireless system integrator with expertise in designing, deploying & supporting wireless data solutions.

More Applications



Solution: SCADA/ M2M Wireless Comm System for Wind Farms
Industry: Utilities - Wind Power Generation
Product(s): WWAN Routers, 3G Data Modems, RF BDA's, Antennas, Long Wireless PtP & PtMp Bridges
Geography: Various in U.S & Canada



Background

Entegrity wind systems was interested in a solution to provide remote real-time data acquisition and control to wind turbines across the country. Working in close partnership with Apterra Technologies, LLC a leading provider of software and systems for remote windfarm management, RfWeL developed various solutions to backhaul RTU data and allow remote access to turbines reliably and cost-effectively.


Contact us to learn more about this solution
Top
Menlo Fire Tower Solution: High Performance Point-to-Point Links w/ Redundancy
Industry: Public Safety - Fire Protection
Product(s): Long range PtP millimeter wave microwave radio (60GHz), 5GHz radio, link aggregation multiWAN router
Geography: U.S.A, Menlo Park, CA



Background

Menlo Park Fire Protection district was interested in replacing their aging T1's and create a high performance link between existing site and a newly acquired site. The cost of laying a new fiber optic link was prohibitive.



To obtain the high performance - high reliability, high full duplex throughput and high security we used unlicensed 60GHz radios which offered exceptional physical security (narrow beamwidth) and data security (AES encryption). For redundancy we used an OFDM-based high performance 5GHz PtP link and bonded the two links for failover & load-balancing using an industry-leading multiWAN router.


Contact us to learn more
Top
Wireless Dynamic Messaging System Solution: Wireless Communication for Dynamic Messaging Signs for Intelligent Transport System
Industry: Public Transport
Product(s): High performance WWAN routers, EVDO modems, Point-to-Point Wireless bridges, Celluar & 5GHz antennas, cable systems.
Geography: U.S.A, Mesa, AZ



Background

The City of Mesa in partnership with Arizona's Valley Metro needed to integrate a remote wireless communication system for a dynamic messaging system for the newly construction Main Street Bus Rapid Transport system.



System includes 3G WWAN systems for remote dynamic messaging system monitoring/control and Point-to-Point (PtP) links as alternative for copper/fiber for cross-link communication.


Contact Us to Learn More

Top
Solar, Wireless Radio, PTZ for Construction Solution: Remote Site Solar for Wireless Video Backhaul
Industry: Large Construction
Product(s): High datarate point-to-multipoint radios, off-grid solar, battery backup, outdoor ptz camera
Geography: Various sites in U.S



Background

Gray Construction a leader in providing engineering, design and construction services to customers in the U.S. and around the world required a high performance PTZ camera to monitor construction sites before power and DSL/Cable/T1 drops were available. Due to the the large coverage zone we required a reliable and high datarate wireless radio link to backhaul live video for remote viewing in construction trailer and remotely at main office. We also required reliable 24x7 off-grid solar to power the system and backup batteries for 72hours of autonomy.



Rfwel's multidisciplinary teams were able to quickly come up with an effective solution that included correctly sizing solar grids per geography & loads and specifying sufficient battery capacity to address the high load demands of high performance Axis PTZ cameras. We also succesfully designed a near-line-of-sight (nLOS) unlicensed point-to-multipoint wireless radio link to backhaul the live video for offsite viewing and storage as well as to send power system status telemetry information.


Learn More about this Solution

Top

EPA Emergency Communication Trailer Solution: Emergency Response Trailer Communications
Industry: Federal Government (EPA)
Product(s): Mobile long-range wireless hotspots w/ combined 3G EVDO/HSPA and 4G WiMax/LTE backhaul
Geography: EPA Region 9 (Pacific Southwest)



Background

For this project for EPA Region 9, Rfwel was tasked with outfitting Emergency Communication Trailers with mobile/nomadic wireless network for use inside the trailer and to provide a wireless hotspot to cover several hundred feet outside the trailer. We needed to utilize 3G/4G public carrier networks in such a way that we had reliable redundancy (since geography-specific signal coverage was not known apriori) as well as sufficient link-aggregation (load-balancing) to allow a good user experience for multiple concurrent users.



We used Peplink load-balancing routers, Cellular/WiMax 3G/4G modems, high gain Cellular/PCS/WiMax/LTE antennas, cellular RF bidirectional amplifiers and multiband diplexers to distribute multiple frequency band antennas using less cables and to same multiband modems.


Learn More about this Solution

Top

Rig at sunset Solution: Wireless Video Audio Transmission
Industry: Oil & Gas
Product(s): Long range PtP bridges, Directional Antennas, Network Storage, Filters
Geography: U.S.A, Oklahoma City, OK



Background

A major oil drilling company needed a solution to remotely view activity in a remote oil rig. This system needed to be rugged to withstand the harsh environment in the rig, good quality and low cost to justify replication in other sites.



They required equipment that was to be used to send two video feeds from an oil drilling rig cabin to the clients office trailer approximately 300 feet apart. Each video feed was to supply the client with numerous views of equipment throughout the drilling rig. The original video was fed into the drilling cabin from eight cameras located throughout the rig which displayed via two monitors in the drilling cabin for the driller to view equipment they normally could not see from their view. Required equipment that could withstand the very rugged environment & potential RF interference from numerous other radios.


Get Full Solution

Top
Solution: Large Coverage WiFi Hotspot & LAN Network, Remote Backhaul
Industry: Large Outdoor Event
Product(s): Outdoor wireless PtMp radios, WWAN routers & 3G Cellular modems, LAN equipment.
Geography: U.S.A, Ossipee Valley - Hiram, ME



Background

Up North Productions Inc. was interested to obtain an economical, reliable and high performance temporary WiFi hotspot and LAN network for their upcoming production. The WiFi hotspot was to cover various zones in the sprawling 5 acre fairground and campsite and to enable Internet connectivity of various ATM, Ticket Scanners, vendor booths & box offices at several venue entrances as well office equipment. The three day music and arts festival approximately was expected to attract five thousand attendees.

The two main challenges that RfWeL faced were how to economically & reliably backhaul the wireless network with enough speed for a good Internet experience and seamless gate & box office operations and how to cover such a large area with a reliable temporary setup with zero downtime and little management from the single on-site technician stationed at the event ...


Contact us for Full Solution
Top
Solution: Indoor authenticated WiFi hotspot, 3G cellular backhaul
Industry: Expo & Conventions
Product(s): WLAN gateway controller w/ AAA server, Multi-WAN cellular routers & 3G modems, WiFi Antennas & Amplifiers
Geography: U.S.A, Mesa, AZ



Background

East Valley Business Expo, a partnership of Chandler, Gilbert, Mesa & Tempe Arizona chamber of commerce was interested to setup a reliable complimentary WiFi hotspot for their annual expos. The temporary wireless network was to cover entire Mesa convention center and was to be free for attendees with authentication. From our success and learning in 2007's expo RfWeL made significant modifications to 2008's system.


Contact us to learn more about this solution
Top
Solution: Large Coverage WiFi for Remote Ticketing
Industry: Entertainment - Large Theatre
Product(s): High Power 802.11 a/b/g AP's
Geography: U.S.A, Phoenix, Arizona


Background

Celebrity theatre one of Phoenix Arizonas most intriguing historing landmarks is a full-service 2,665 people capacity entertainment facility. They needed to provide a secure & isolated WiFi network at various entrances and regions within the facility to allow for portable hand-held ticket scanners. Since the scanners utilized an embedded 802.11a/b/g WLAN radio with no external antenna connections it was important to create a strong WiFi signal to reach the designated points where they needed to be used but without unduly interfering with other AP's & other WLAN's in the same 2.4GHz unlicensed band.


Contact us to learn more about this solution
Top
Solution: Remote HVAC control, Wireless Thermostats
Industry: Hotels & Resorts
Product(s): Programmable wireless thermostats
Geography: U.S.A, Sedona, AZ



Background

When the Radisson Poco Diablo Hotel in beautiful Sedona Arizona were in the process of renovating their 138 room hotel to include quality resort amenities they turned to RfWeL to provide self-controlled wireless thermostats and receivers to guarantee that guest comfort level was extremely pleasant. With careful equipment selection & RF sub-channel selection their chief engineer was able to economically and rapidly implement a feature that provides their Hotel a key differentiating amenity.


Contact us to learn more about this solution
Top
CPI Corp   Wal-mart portrait studio
Sears portrait studio
Solution: Cellular 3G broadband Internet
Industry: Large multi-store Retail
Product(s): Cellular WWAN routers, Cellular antennas & cellular band RF amplifiers/repeaters
Geography: Various across North America



Background

CPI Corp is the leading portrait studio operator in North America offering photography services in more than 3100 locations principally in Sears and Wal-Mart stores.



There was a need to separate the LAN Internet network of the portrait studios from that of the host retail establishment. Rfwel provided the cellular 3G WWAN routers to create a reliable isolated LAN network. In stores without a sufficiently strong or reliable cellular 3g signal we provided cellular bi-directional amplifiers/repeaters and high gain cellular band antennas.


Contact us to learn more about this application
Learn more about Business Continuity solutions more
Top
Solution: Remote Redundant Wireless Data Network
Industry: Finance, Multibranch Large Enterprise
Product(s): Multi-WWAN 3G router, 3G modems, Loadbalance, link aggregation, failover, Cellular antennas & RF amplifiers
Geography: Various across rural U.S



Background

A large privately held non-bank owned Mortgage Company approached us early one Friday afternoon to provide remote wireless Internet solutions to several new branches under construction in rural markets across the U.S. Many of these locations were well past their grand opening and for many the deadlines were rapidly approaching. T1 roll outs were in weeks to months! By monday afternoon RfWeL had enabled basic Internet in 5 locations and with a few tweaks had VPN and advanced networking features available end of day monday. By the end of week all locations within several miles of a cellular tower offering 3G data service were lit up. By the careful selection of cellular carrier, antenna, antenna orientation, amplifiers and enterprise-class multi-wan routers we were able to create a highly redundant, highly scaleable and high speed network that clearly wowed and eased the worry of edgy management.


Contact us to learn more about this solution
Learn more about Business Continuity solutions more
